67.2V Electric Vehicles Battery Charger

SKU
67.2V battery charger
In stock
Shipping cost around: 34$ to 69$ delivery to United States
$69.50
-
+
Overview
  • Please check the plug and connector carefully when you place the order.
  • AC Input: 100-120V/220-240V/100-240V
  • Material: Aluminum alloy with Fan
  • Application: Electric Vehicles & Tools
  • Various Protection: Over current, Over Voltage, Over Temperature, Short Circuit and reverse polarity.
  • The product can be Customized!

Charger

Battery matched

42V4A/5A

36V battery

54.6V4A/5A

48V battery

58.8V4A/5A

52V battery

67.2V4A/5A

60V battery

84V4A/5A

72V battery

42V 4A 5A 10A  Lithium Battery Charger for electric bike electric scooter

This charger with multi-protection is suitable for electric three-wheel, electric bike or other EV products. it is an automatic smart intelligent charger, easy to use and carry, durable and high efficiency. It is a good choice for your electric vehicle.



Advantage :

1. Full automatic transition of CC CV and float/cut-off (CC CV 3 stage charger).

2. Precise limit of voltage& current, guarantee fully charged and avoid over charger.

3. Protections: short circuit, over voltage, over temperature, reverse polarity protection, Dc output isolated from AC input.

4. High Efficient : > 85% PFC :0.96 Eco-friendly.

5. Current & voltage display. Two led indicators LED1 Red ( power on ), LED 2 Red/Green ( charging/full )

6. Safety and high quality, Advantage high-frequency switching mode power supply technology

7. CE ROSH, CB.

7.Aluminum housing, lightweight, portable, elegant and reliable.



Feature :
1. Aluminum case, lightweight
2. Input voltage ; AC 100 V ~240 V 50 / 60 HZ
3. Charge mode : 3 stage ( CC CV float mode )
4. Charging: High saturation and efficiency
5. Input plug(power cords): EU US UK AUS Italy Plugs etc ( can be Customized)
6. Output Connector: DC jack, XLR, JST, Cigar Lighter, Alligator Clips etc



The 3-stage mode charging :

The first stage ( constant current ): The charger will supply constant current for the battery.

The second stage ( constant voltage ): The voltage will be rising under the first stage. When it reaches constant voltage value, it will turn into the second stage. The current will be slowly smaller until it reduces to floating value, the CV stage will end.

The third stage ( Floating charging ): When the current is approaching the value of transition, the charger will cut down to the given current gradually, that means the battery power is full and indicator light turns to green. At this moment, the battery can be stopped charging or keep on trickle current charging for half an hour.

battery charger

(1) How to calculate the charging voltage for the battery?

Normally single cell charging voltage for li-ion is 4.2V, charging voltages for batteries are as follows:

24V Li-ion battery (7 cells in series): 7x4.2V=29.4V;

36V Li-ion battery (10 cells in series): 10x4.2v=42V

48V Li-ion battery (13 cells in series): 13x4.2v=54.6V

60V Li-ion battery (16 cells in series): 16x4.2v=67.2V

72V Li-ion battery (20 cells in series): 20x4.2v=84V

If your battery is different voltage, please inform us. Or if your battery is with different cells number in series, you can calculate the charging voltage yourself.

(2) How to calculate the charging time for the battery?

The charge time depends on the battery chemistry and the charge current.
Discharge time is basically the Ah or mAh rating divided by the current.

So for an 11.6mAh battery with a load that draws 2A, the charging time is about:

11.6/2=5.8hours

More Information
Material Aluminum alloy with Fan
Weight N/A
Color N/A
Install way N/A
Rim size N/A

1x 67.2V4A or 67.2VX5A battery charger
